Husqvarna 136 is our smallest chain saw and
is intended for homeowner use. Our main focus,
as always, is on the user and the work environment
and our demands on safety, function, ergonomics
and reliability are as important as our demands
on our tools for forestry professionals. Easy
to start and flexible, and standard-equipped
with our LowVib chain. |
|
 |
Air
Injection
Air Injection. Centrifugal air cleaning system
for longer intervals between filter cleanings,
smoother operation and reduced wear. |
 |
The
two mass principle
Vibration dampening with the handles isolated
from the engine |
 |
Better grip
Angled front handle for better grip and natural
working position. |
 |
Safer to use
Double acting chain brake, right hand guard
and chain catcher make the saw safer to use.
|
 |
Easy
to work with
The slim body, high center of gravity and
flat underside make our saws easy to work
with. |
 |
Three-piece crankshaft
Forged three-piece crankshaft for maximum
durability for the toughest applications.
|
| 136 |
| Cylinder
displacement |
2.2 cu.inch / 36.3 cm³ |
|
Power |
2.2 hp / 1.6 kW |
| Maximum
recommended engine speed |
13
000 mm |
| Fuel
tank volume |
0.85 US pint / 0.41l |
| Oil
tank volume |
0.42
US pint / 0.20l |
| Oil
pump type |
fixed flow |
| Cutting
equipment |
| Chain
pitch |
.325" |
| Recommended
bar length |
13-15"
/ 33-38 cm |
Ergonomics
|
| Sound
level |
98
dB(A) |
| Noise
emissions, LWA |
118
dB(A) |
| Vibrations,
front/rear handle |
4.9 m/s² / 7.7 m/s² |
Overall dimensions
|
| Weight
excl. cutting equipment |
10.1
lbs / 4.6 kg |
| Advantages |
-
Low noise level
-
Low weight on all moving engine parts
means fast acceleration.
|
